Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT801
$6.53
Regular price
$14.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APBT801
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APBT801 Full Copper Threaded Tee Fitting Specifications
- Model: X-APBT801
- Type: Equal Tee (Straight Thread)
- Material: Lead-free brass (CW617N)
- Thread Standard: BSPP (Parallel) / ISO 228-1
- Port Sizes: 1/8" (G1/8) × 3 ports
- Thread Length: 12mm (engagement length)
- Max Working Pressure: 1.5 MPa (15 bar)
- Temperature Range: -20°C to 120°C
- Surface Finish: Electroplated nickel (3-5μm thickness)
- Weight: 28g ±1g
- Dimensions: 24mm(L) × 24mm(W) × 24mm(H)
- Flow Coefficient (Cv): 0.22
- Leakage Class: Class 4 per ISO 6952
- Certifications: RoHS compliant, REACH SVHC-free
Precision-machined brass tee connector with triple sealing surfaces, designed for stable branching in pneumatic systems. Features corrosion-resistant nickel plating and stress-relieved threads for repeated assembly. Compatible with air, inert gases, and water-based fluids.
Typical Applications:
- Pneumatic circuit distribution in automation equipment
- Coolant line branching for CNC machine tools
- Vacuum system junctions in packaging machinery
- Instrumentation air supply networks
- Compressed air tool manifolds
Installation note:
Apply thread sealant only on male threads (not required for BSPP-to-BSPP connections).
Tightening torque range: 12-15 N·m. Avoid overtightening to prevent thread deformation.
| Property | Property Value |
|---|---|
| sku | X-APBT801 |
