Airtac X-APBT Connector - Full Brass Thread Straight Tee X-APBT802
AirTAC X-APBT802 Full Copper Threaded Straight Tee Fitting Specifications
- Model: X-APBT802
- Material: Lead-free brass (CW617N)
- Thread Standard: BSPP (G thread) / NPT optional
- Port Configuration: 3-way equal diameter
- Thread Size: 1/8" (R1/8, G1/8, or NPT1/8)
- Max Working Pressure: 1.5 MPa (217 psi)
- Burst Pressure: ≥4.5 MPa
- Temperature Range: -20℃ to 120℃
- Surface Treatment: Electroplated nickel (3-5μm thickness)
- Seal Compatibility: Compatible with air, water, and non-corrosive gases
- Weight: 28±2g
- Dimensions: 32mm(L) × 25mm(W) × 25mm(H)
- Torque Specification: 12-15 N·m installation torque
- Certification: RoHS compliant, REACH SVHC-free
Precision-machined copper tee fitting with triple-directional flow control, featuring CNC-turned threads for leak-proof connections. The nickel-plated surface provides enhanced corrosion resistance in humid environments. Internal bore maintains laminar flow with <0.2mm surface roughness (Ra).
- Pneumatic system branch line distribution
- Coolant line splitting in CNC machines
- Compressed air manifold assemblies
- Hydraulic test bench configurations
- Vacuum system junction points
Installation protocol:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Avoid overtightening beyond 15N·m to prevent thread deformation.
Recommended to use with AirTAC APTF series thread sealant for high-vibration environments.
| Property | Property Value |
|---|---|
| sku | X-APBT802 |
