Airtac X-APC Threaded Straight Connector X-APC10M10
AirTAC X-APC10M10 Threaded Straight Connector Specifications
- Model: X-APC10M10
- Type: Metric thread straight-through fitting
- Thread specification: M10×1.0 (male thread both ends)
- Material: Brass CW617N (nickel-plated surface)
- Seal material: NBR (Nitrile) O-ring
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to +80℃
- Burst pressure: ≥6 MPa
- Surface treatment: Electroless nickel plating (5-8μm)
- Weight: 28±2g
- Dimensions: 42mm(L) × 14mm(W) × 14mm(H)
- Compatibility: Air, inert gases, and oil-free environments
- Certifications: RoHS compliant, REACH compliant
Precision-machined straight connector with dual male threads, designed for leak-free connections in pneumatic systems. Features corrosion-resistant nickel plating and cold-forged brass construction for superior mechanical strength. The embedded NBR seal ensures airtight performance under vibration.
- Pneumatic cylinder port extensions
- Modular assembly in automation equipment
- Sensor mounting brackets in packaging lines
- Air preparation unit plumbing
- Robotic end-effector pneumatic connections
Installation note:
Apply thread sealant (LOCTITE 577 recommended) on male threads before assembly.
Tightening torque should not exceed 15N·m. Avoid overtightening to prevent
deformation of sealing surfaces. For vertical installations, orient O-ring
groove downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | X-APC10M10 |
