Airtac X-APC Threaded Straight Connector X-APC1403
AirTAC X-APC1403 Threaded Straight Connector Technical Details
- Model: X-APC1403
- Type: Metric thread through connector
- Thread standard: ISO 6149 (Metric Fine Thread)
- Thread size: M14×1.5 (male thread both ends)
- Material: Cold forged carbon steel (Zn-Ni plating)
- Max working pressure: 25 MPa (3625 PSI)
- Burst pressure: 75 MPa
- Temperature range: -30℃ to +120℃
- Surface hardness: 550-750 HV
- Seal type: Metal-to-metal sealing
- Corrosion resistance: 240h salt spray passed
- Weight: 84g ±2g
- Dimensions: 44mm(L) × 14mm(Dia) × 14mm(Thread length)
- Compliance: RoHS 2.0 compliant
High-pressure hydraulic connector with precision-machined metric threads, designed for leak-free connections in rigid piping systems. Features triple-sealing structure with primary metal seal, secondary O-ring (NBR optional), and thread adhesive layer. Includes anti-vibration grooves for stable torque transmission.
- Hydraulic power unit manifold blocks
- Construction machinery pressure sensors
- Plastic injection molding machine oil circuits
- CNC machine tool lubrication systems
- Agricultural equipment hydraulic cylinders
Installation protocol:
Apply 2-3 drops of LOCTITE 577 thread sealant before assembly.
Tighten to 45-50 N·m torque using crowfoot wrench.
Do NOT use with PTFE tape. Max re-use cycles: 5 times.
