Description
AirTAC X-APD10M16 T-Type Threaded Tee Fitting Specifications
- Model: X-APD10M16
- Type: T-shaped pneumatic tee connector
- Thread standard: Metric fine thread (T-type)
- Port size: M16×1.5 (all three ports)
- Material: Brass with nickel plating
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -5℃ to 80℃
- Installation torque: 20-25 N·m max
- Surface roughness: Ra ≤3.2μm
- Weight: 48±2g
- Dimensions: 50mm(L) × 16mm(W) × 16mm(H)
- Seal compatibility: Compatible with NBR/PU/Urethane seals
- Certifications: RoHS compliant, REACH SVHC-free
Precision-machined brass tee connector featuring corrosion-resistant nickel plating and leak-proof design. The T-shaped configuration enables 90° branch line connections in compact pneumatic systems. Includes precision-machined threads with ±0.01mm tolerance for bubble-tight sealing.
Typical Applications:
- Pneumatic circuit branching in automation equipment
- Air preparation unit manifold connections
- Multi-axis robotic arm pneumatic networks
- Packaging machine air distribution systems
- CNC machine tool pneumatic control lines
Installation guide:
Apply thread sealant (PTFE tape or liquid sealant) to male threads before assembly.
Tighten using a crowfoot wrench for even torque distribution.
Avoid overtightening - maximum 1.5 full turns after hand-tight.
Environmental resistance:
- Salt spray test passed: 96hrs (NSS test per ASTM B117)
- Vibration resistance: 10-500Hz, 5G acceleration
- IP rating: IP54 when properly installed
| Property | Property Value |
|---|---|
| sku | X-APD10M16 |
