Airtac X-APD Connector - T-Type Threaded Tee X-APD12M16
AirTAC X-APD12M16 T-Port Threaded Tee Fitting Technical Details
- Model Code: X-APD12M16
- Series: X-APD (Compact Pneumatic Fittings)
- Type: T-shaped triple port manifold
- Thread Standard: Metric fine thread (T-type)
- Port Configuration: M16×1.5 female threads (all three ports)
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Pressure Rating: 0.05-1.5 MPa (7-217 PSI)
- Burst Pressure: ≥3.0 MPa (435 PSI)
- Temperature Range: -20℃ to 120℃ (continuous operation)
- Seal Material: NBR (Nitrile) O-rings
- Surface Hardness: HV0.3 120-200 (nickel coating)
- Leakage Rate: <3×10⁻² Pa·m³/s (helium test)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Weight: 78g ±2g
- Dimensions: 32mm (L) × 28mm (W) × 28mm (H)
- Certifications: RoHS compliant, ISO 9001:2015
High-density machined tee connector with precision-milled flow channels, engineered for stable pressure distribution in multi-branch pneumatic circuits. The electroless nickel plating provides corrosion resistance against water vapor and mild chemicals. Features triple sealing points with pre-lubricated NBR rings for zero-leak performance.
- Branch line creation in CNC machine tool air supply systems
- Modular pneumatic manifold assemblies for packaging machinery
- Three-way pressure monitoring setups in industrial automation
- Compressed air distribution in automotive assembly robots
- Vacuum system junction points for material handling equipment
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 14-16 N·m torque using crowfoot wrench. Avoid overtightening
which may distort O-ring grooves. Perform pressure test at 1.25×
working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APD12M16 |
