Airtac X-APD Connector - T-Type Threaded Tee X-APD1604
AirTAC X-APD T-Port Tee Fitting (X-APD1604) Detailed Specifications
- Model: X-APD1604
- Type: T-shaped metric threaded tee connector
- Material: Nickel-plated brass (base) + PPSU (polyethersulfone) housing
- Thread Standard: M5×0.8 tapered (BSPP) female threads
- Port Configuration: 3-way equal distribution (T-shaped flow path)
- Max Working Pressure: 1.5 MPa (217 psi)
- Burst Pressure: 4.5 MPa (653 psi)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: HNBR (Hydrogenated Nitrile) O-rings
- Surface Treatment: Electroless nickel plating (5-8μm thickness)
- Weight: 28g ±2g
- Dimensions: 24mm (L) × 19mm (W) × 19mm (H)
- Flow Coefficient (Cv): 0.15
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant, REACH SVHC-free
Precision-engineered T-connector featuring triple-seal technology with 30° conical seat design for leak-free performance in high-vibration environments. The hybrid metal-polymer construction balances durability with chemical resistance, optimized for compressed air and inert gas systems. Includes integrated particle filtration grooves (40μm) to prevent downstream contamination.
- Modular pneumatic manifolds in assembly robots
- Branch line distribution for CNC machine tool cooling systems
- Vacuum circuit splitting in packaging machinery
- Sensor air supply networks in semiconductor fabs
- Medical gas panel distribution blocks
Installation protocol:
Apply 2-3Nm torque using flank-centered wrench. For vertical mounting,
orient flow arrow upward. Requires thread sealant (LOCTITE 577 recommended)
for non-ported seal applications. Perform pressure test at 110% max operating
pressure for 5 minutes post-installation.
| Property | Property Value |
|---|---|
| sku | X-APD1604 |
