Airtac X-APD Connector - T-Type Threaded Tee X-APD16M20
AirTAC X-APD16M20 T-Port Tee Threaded Fitting Detailed Specifications
- Model: X-APD16M20
- Type: T-shaped pneumatic tee connector (male thread)
- Material: Brass with nickel plating (stainless steel optional)
- Thread specification: M20×1.5 metric fine thread (ISO 6149 compliant)
- Port configuration: Three M20 ports (1 inlet, 2 outlets at 90°)
- Operating pressure: 0.05-1.5 MPa (7-217 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) O-rings (FKM/Viton optional)
- Proof pressure: 3.0 MPa (435 PSI)
- Surface treatment: Electroless nickel plating (3-5μm thickness)
- Installation torque: 40-50 N·m (29.5-36.9 lb-ft)
- Weight: 85g (brass version) / 210g (stainless steel version)
- Dimensions: 30mm (L) × 25mm (W) × 25mm (H)
- Flow coefficient (Cv): 2.4 (at 6 bar)
- Compliance: RoHS compliant, REACH certified
Precision-engineered T-connector featuring triple M20 ports with industrial-grade sealing, designed for high-pressure pneumatic systems requiring stable branch connections. The 90° outlet configuration optimizes space utilization in compact manifolds while maintaining laminar airflow characteristics. Features anti-vibration thread design with integrated torque shoulders.
- Pneumatic distribution blocks in automated assembly lines
- Compressed air branching for CNC machine tooling
- Industrial robot end-effector air supply systems
- Packaging machinery pressure balancing circuits
- Semiconductor manufacturing gas delivery networks
Installation protocol:
Apply PTFE tape or liquid sealant on male threads before assembly.
Use calibrated torque wrench to prevent over-tightening.
Align ports within 5° of desired orientation before final tightening sequence.
| Property | Property Value |
|---|---|
| sku | X-APD16M20 |
