Airtac X-APD Connector - T-Type Threaded Tee X-APD402
AirTAC X-APD402 T-Port Tee Threaded Fitting Specifications
- Model: X-APD402
- Type: T-shaped tee connector (triple port)
- Thread standard: Metric tapered (PT) / BSPT
- Port configuration: 3-way M5×0.8 female threads
- Material: Nickel-plated brass (base), NBR seals
- Pressure rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Flow coefficient (Cv): 0.15
- Weight: 28g ±2g
- Dimensions: 25mm(L) × 25mm(W) × 25mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered tee connector with corrosion-resistant nickel plating, designed for compact pneumatic circuit branching. Features 360° rotatable ports for flexible tubing alignment and a double O-ring structure that maintains seal integrity under pulsating pressures. Compatible with ISO 15407-1 standard pneumatic systems.
- Modular pneumatic control panels
- Robotic end-effector air distribution
- Medical device gas line manifolds
- Semiconductor wafer handling systems
- Multi-axis actuator synchronization circuits
Installation protocol:
Apply PTFE tape on male threads using clockwise winding direction.
Tighten to 1.2-1.5 N·m torque maximum. Avoid overtightening which may
cause port deformation. Perform pressure test at 1.25×operating
pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APD402 |
