Airtac X-APD Connector - T-Type Threaded Tee X-APD4M12
AirTAC X-APD T-Port Tee Fitting (X-APD4M12) Full Specifications
- Model: X-APD4M12
- Type: Metric T-style pneumatic tee connector
- Thread standard: M12×1.5 male threads (triple ports)
- Material: Anodized aluminum alloy 6061-T6
- Seal type: Dual NBR O-rings (per ISO 3601)
- Pressure rating: 0.05-1.0 MPa (7-145 psi)
- Burst pressure: ≥3.0 MPa (435 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Surface treatment: Black electrophoretic coating
- Flow capacity: 250 NL/min @ 0.5 MPa
- Weight: 82g ±2g
- Dimensions: 40mm (L) × 20mm (W) × 20mm (H)
- Port configuration: Three M12 male ports at 90° angles
- Installation torque: 8-12 N·m recommended
- Compliance: RoHS 2.0 compliant
High-density T-connector featuring anti-vibration thread design with double-sealed ports for leak-free pneumatic connections. The hexagonal body allows wrench tightening while the corrosion-resistant coating withstands industrial environments. Optimized internal flow path reduces pressure drop by 18% compared to standard tees.
- Branching pneumatic circuits in robotic end effectors
- Modular assembly of FRL (Filter-Regulator-Lubricator) units
- Sensor mounting platforms in automated packaging lines
- Distributing air supply in CNC machine tool manifolds
- Mobile equipment pneumatic systems (agricultural/construction)
Installation best practice:
Apply thread sealant only on male threads (Type PTFE recommended).
Avoid overtightening - use torque wrench for precise installation.
Maximum angular misalignment tolerance: ±3° between connected components.
| Property | Property Value |
|---|---|
| sku | X-APD4M12 |
