Airtac X-APD Connector - T-Type Threaded Tee X-APD4M5
AirTAC X-APD4M5 T-Type Threaded Tee Fitting Specifications
- Model: X-APD4M5
- Type: T-port threaded tee connector (triple outlet)
- Material: Brass with nickel plating (anti-corrosion surface)
- Thread standard: Metric fine thread (T-type)
- Thread size: M5×0.8 (male threads on all ports)
- Port configuration: 3-way equal diameter (L-shaped flow path)
- Max working pressure: 1.5 MPa (15 bar / 217.5 psi)
- Temperature range: -5℃ to 80℃ (non-condensing environment)
- Seal material: NBR (Nitrile O-rings)
- Surface hardness: HV0.3 ≥210 (nickel layer)
- Weight: 8.2±0.5 grams
- Dimensions: 16mm (L) × 16mm (W) × 21mm (H)
- Torque specification: 1.2-1.5 N·m during installation
- Compatibility: Works with Φ4mm OD pneumatic tubing
A precision-machined flow distribution component designed for compact pneumatic systems. Features 360° rotatable ports for flexible piping alignment and leak-proof conical thread design. The electroless nickel coating provides chemical resistance against mild acids and hydraulic fluids.
- Branch circuit creation in SMC-type pneumatic manifolds
- Modular assembly in 3D printer air distribution systems
- Medical device gas line splitting (oxygen concentrators, dental tools)
- Robotic gripper pneumatic circuit expansions
- Laboratory instrument air supply distribution
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads at 45° angle.
Tighten using a crowfoot wrench to prevent port misalignment.
Maximum 120° rotation after initial seal contact.
| Property | Property Value |
|---|---|
| sku | X-APD4M5 |
