Airtac X-APD Connector - T-Type Threaded Tee X-APD4M6
AirTAC X-APD T-Port Tee Fitting (X-APD4M6) Technical Details
- Model: X-APD4M6
- Type: Metric T-shaped pneumatic tee connector
- Thread standard: M6×1.0 straight metric thread (male threads)
- Material: Brass (CuZn39Pb3) with nickel-plated surface
- Seal material: NBR (Nitrile) O-rings (pre-installed)
- Pressure rating: 0.05-1.0 MPa operating range
- Temperature range: -20℃ to 80℃ (continuous use)
- Port configuration: Three M6 ports (1 vertical, 2 horizontal)
- Surface roughness: Ra ≤1.6μm at sealing surfaces
- Anti-vibration: Thread lock compound pre-applied
- Weight: 12.5g ±0.3g
- Dimensions: 19mm (L) × 19mm (W) × 24mm (H)
- Torque specification: 1.2-1.5 N·m during installation
- Compliance: RoHS 2.0 compliant
Precision-machined tee connector with triple-port flow paths for compact pneumatic distribution systems. Features corrosion-resistant nickel plating and cold-forged construction for enhanced durability. The 60° cone seating design ensures leak-free connections even under pulsating pressure conditions.
- Branch line creation in FRL (Filter-Regulator-Lubricator) units
- Modular pneumatic circuit extensions in automation cells
- Sensor mounting platforms with auxiliary air supply
- Medical device pneumatic manifolds requiring hygienic connections
- Robotic end-effector air line distribution
Installation protocol:
Use two wrenches during assembly - one to counter-hold the base fitting
while tightening adjacent components. Apply supplemental pipe sealant
only to male threads, avoiding contact with the first two thread crests.
| Property | Property Value |
|---|---|
| sku | X-APD4M6 |
