Airtac X-APD Connector - T-Type Threaded Tee X-APD4M8
AirTAC X-APD4M8 T-Port Tee Fitting Detailed Specifications
- Full Model: X-APD4M8-T
- Type: Metric T-style pneumatic tee connector
- Thread Standard: M8×1.0 male threads (triple ports)
- Material: CNC-machined C3604 brass with chrome plating
- Seal Type: Embedded EPDM O-ring (FDA compliant)
- Pressure Range: 0.05-1.5 MPa (7-217 PSI)
- Temperature Range: -20°C to 120°C (continuous)
- Flow Capacity: 400 NL/min @ 0.5 MPa
- Surface Finish: 0.8μm Ra chromium coating
- Vibration Resistance: 10-2000 Hz, 20G acceleration
- Weight: 28.5±0.5g
- Dimensions: 24mm (L) × 24mm (W) × 24mm (H) - cube body with 15mm projection per port
- Certifications: RoHS 3, REACH, ISO 16030 compliant
- IP Rating: IP44 (standard sealing)
Precision-engineered T-connector featuring triple M8 male ports in orthogonal configuration, designed for compact pneumatic distribution systems. The hexagonal body allows tool tightening (8mm wrench flat) while the 24° cone seat design prevents O-ring extrusion. Includes anti-vibration thread locking features for mobile applications.
- Modular pneumatic manifolds in SMT equipment
- Sensor air supply branching in robotic arms
- Vacuum circuit distribution for pick-and-place systems
- Medical device gas line splitting (oxygen concentrators)
- Electric vehicle brake air system junctions
Installation protocol:
Apply thread sealant only on male threads (PTFE tape not recommended).
Tighten to 2.5-3.0 N·m torque using crowfoot wrench.
Perform pressure test at 1.8×system pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APD4M8 |
