AirTAC X-APD602 T-Port Threaded Tee Fitting Specifications
- Model: X-APD602
- Type: T-shaped pneumatic tee connector (male thread)
- Body material: Brass (nickel-plated)
- Seal material: NBR (nitrile rubber)
- Thread standard: T-thread (ISO 1179 compliant)
- Port configuration: M5 × 3 ports (1 inlet, 2 outlets)
- Operating pressure: 0.3-1.5 MPa
- Temperature range: -20℃ to 80℃
- Max flow rate: 300 NL/min
- Weight: ~85g
- Dimensions: 30mm(L) × 20mm(W) × 20mm(H)
- Surface roughness: Ra ≤3.2μm
- Leakage rate: ≤0.1 mL/min at 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
High-density brass tee connector with precision-machined T-threads for secure branching in pneumatic circuits. Features triple-sealing design with embedded O-rings and anti-vibration grooves. Compatible with ISO 15407-1 standard components.
Typical Applications:
- Pneumatic manifold splitting in automation equipment
- Modular air circuit distribution in production lines
- Compressed air branching for robotic end effectors
- Vacuum system tee connections
- CNC machine tool pneumatic networks
Installation note:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten).
Maximum recommended torque: 1.2 N·m. Align ports within 5° deviation
during assembly. Perform pressure test at 1.8 MPa after installation.
| Property | Property Value |
|---|---|
| sku | X-APD602 |
