Airtac X-APD Connector - T-Type Threaded Tee X-APD603
AirTAC X-APD603 T-Port Tee Fitting Technical Specifications
- Model: X-APD603
- Type: T-shaped pneumatic tee connector (female thread all ports)
- Thread standard: Metric T-type (ISO 228 G-series compatible)
- Port configuration: 3-way equal diameter
- Thread size: PT1/8 (G1/8 equivalent)
- Material: Lead-free brass (CuZn39Pb0.5) with nickel plating
- Surface hardness: ≥HV200
- Pressure rating: 0.05-1.5 MPa (7-217 PSI)
- Burst pressure: ≥3.0 MPa
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal material: NBR (Nitrile) standard (FKM/Viton optional)
- Weight: 28±2g
- Dimensions: 20mm(L) × 20mm(W) × 20mm(H)
- Surface roughness: Ra≤1.6μm
- Torque resistance: ≤25N·m
Precision-machined brass tee connector featuring triple-ported design with unified thread specifications for bidirectional flow control. The electro-less nickel plating provides enhanced corrosion resistance exceeding 96hrs salt spray test (ASTM B117). Optimized internal flow path reduces turbulent losses by 18% compared to standard tees.
- Pneumatic circuit branching in automation equipment
- Pressure gauge manifold connections
- Multi-cylinder synchronization systems
- Compressed air distribution in CNC machines
- Vacuum system junction points
- Instrumentation calibration setups
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads. Tighten with 12-15N·m torque using flank-contact wrench.
Avoid axial misalignment exceeding 3°. For vertical installations, position flow arrow upward.
