Airtac X-APD Connector - T-Type Threaded Tee X-APD604
AirTAC X-APD604 T-Port Tee Fitting Technical Details
- Model: X-APD604
- Type: T-shaped pneumatic tee connector (equal branch)
- Thread standard: BSPT (Taper thread) / NPT optional
- Port configuration: 3-way (1 inlet, 2 outlets at 90°)
- Thread size: PT1/4 (G1/4 equivalent)
- Material: Brass (CuZn39Pb3) with nickel-plated finish
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 120℃
- Weight: 65g ±2g
- Dimensions: 21mm(L) × 21mm(W) × 24mm(H)
- Seal compatibility: Compatible with NBR, EPDM, and FKM seals
- Surface hardness: ≥HV200
- Proof pressure: 3.0 MPa (435 psi)
- Leakage rate: ≤3 bubbles/min under 0.5 MPa air pressure
Precision-machined tee connector featuring dual-stage sealing with primary metal-to-metal thread contact and secondary O-ring backup. The asymmetric internal flow channels reduce turbulence by 18% compared to standard tees. Nickel plating provides corrosion resistance exceeding 96hrs in salt spray tests.
- Branching pneumatic circuits in robotic end effectors
- Modular pneumatic manifold systems
- Compressed air distribution in CNC machinery
- Vacuum line splitting for pick-and-place systems
- Instrumentation air supply networks
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 2.5-3 N·m torque using flank-contact wrench.
Avoid overtightening - maximum 1/2 turn after finger-tight.
| Property | Property Value |
|---|---|
| sku | X-APD604 |
