Airtac X-APD Connector - T-Type Threaded Tee X-APD6M10
$3.53
Regular price
$11.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APD6M10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APD6M10 T-Port Tee Fitting Detailed Specifications
- Model: X-APD6M10 (T-Type Threaded Tee)
- Thread Standard: Metric T-type (Triangular Thread)
- Port Configuration: 3-way equal tee (T-port design)
- Thread Size: M10×1.0 (Fine pitch)
- Material: Lead-free brass CW617N (Nickel-plated surface)
- Surface Treatment: Electroless nickel plating ≥12μm
- Pressure Rating: 0.05-1.5 MPa (7-217 PSI)
- Burst Pressure: ≥6.0 MPa
- Temperature Range: -5℃ to 80℃ (23℉ to 176℉)
- Seal Material: NBR (Nitrile) O-rings
- Flow Coefficient (Cv): 0.45
- Weight: 28g ±1g
- Dimensions:
- Body Length: 22mm
- Port-to-Port Distance: 18mm (vertical/horizontal)
- Hex Size: 14mm AF
- Compliance: RoHS 2.0, REACH
Precision-machined T-connection for compressed air systems, featuring corrosion-resistant nickel plating and precision ground threads. The 60° tapered seat design ensures bubble-tight sealing under vibration. Compatible with ISO 1179-2 standard fittings.
Typical Applications:
- Branch line creation in pneumatic control panels
- Modular pneumatic circuit prototyping
- Air preparation unit plumbing
- Robotic arm tooling air distribution
- Medical gas line manifolds (non-oxygen service)
Installation guidelines:1. Use torque wrench at 12-15 N·m (hand-tighten plus 1/4 turn)
2. Apply thread sealant only on male threads (PTFE tape recommended)
3. Avoid axial stress - support connected tubing within 150mm
4. Pressure test at 1.25×max operating pressure after installation
Note: Not recommended for:
- Pulsating applications above 2 Hz
- Thermal cycling environments >80℃
- Chemical media incompatible with NBR seals
- Pulsating applications above 2 Hz
- Thermal cycling environments >80℃
- Chemical media incompatible with NBR seals
| Property | Property Value |
|---|---|
| sku | X-APD6M10 |
