Airtac X-APD Connector - T-Type Threaded Tee X-APD6M12
AirTAC X-APD T-Port Tee Connector X-APD6M12 Technical Details
- Model: X-APD6M12
- Type: T-shaped metric threaded tee connector
- Material: Brass (nickel-plated surface)
- Thread standard: Metric ISO 228 (G-thread compatible)
- Port configuration: 3-way equal diameter T-port
- Thread size: M12×1.5 (male threads on all ports)
- Max working pressure: 1.5 MPa (217 psi)
- Pressure rating at 20℃: 0.05-1.5 MPa
- Temperature range: -5℃ to 80℃
- Weight: 15.3±0.5g
- Dimensions: 19.8mm(L) × 18.4mm(W) × 22.6mm(H)
- Surface roughness: Ra ≤1.6μm
- Leakage rate: <5×10⁻⁴ Pa·m³/s under 0.5 MPa
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Compliance: RoHS 2011/65/EU
Precision-machined brass tee connector with triple sealing grooves, designed for high-density pneumatic distribution systems. Features anti-vibration thread design with 30% increased engagement surface compared to standard tees. Nickel plating provides corrosion resistance in humid environments (up to 95% RH non-condensing).
- Modular pneumatic manifolds in packaging machinery
- Branch line connections for robotic EOAT tooling
- Compressed air distribution in automotive assembly lines
- Laboratory pneumatic instrument clusters
- Mobile equipment air brake systems
Installation protocol:
Apply 2.5±0.5 wraps of PTFE tape on male threads (tape width ≥12mm).
Hand-tighten first, then apply 3.5-4.2 N·m torque using crowfoot wrench.
Avoid aligning ports vertically downward in dusty environments.
- Sealing: Compatible with AS568-012 O-rings
- Tools: Requires 19mm thin-wall socket for confined spaces
- Adapters: Converts to NPT/BSPP via X-APD6M12-xx series converters
| Property | Property Value |
|---|---|
| sku | X-APD6M12 |
