Airtac X-APD Connector - T-Type Threaded Tee X-APD6M16
$3.94
Regular price
$11.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APD6M16
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APD6M16 T-Port Threaded Tee Fitting Specifications
- Model: X-APD6M16
- Type: T-shaped triple port with unified thread (male-male-female)
- Thread standard: Metric tapered (T-type) DIN 3852-A
- Port configuration: 2×M16×1.5 male, 1×M16×1.5 female
- Material: CNC-machined lead-free brass (CuZn39Pb3)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Pressure rating: 0.05-1.6 MPa (7-232 PSI)
- Burst pressure: ≥5.0 MPa
- Temperature range: -20℃ to 120℃ (static), -5℃ to 80℃ (operating)
- Seal compatibility: NBR, FKM, EPDM (pre-installed NBR O-ring)
- Weight: 84g ±2g (including packaging)
- Dimensions: 52mm (L) × 32mm (W) × 32mm (H)
- Flow coefficient (Cv): 0.45
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Corrosion resistance: 96hrs salt spray test (NSS)
Precision-engineered tee connector featuring triple sealing surfaces with redundant leak prevention. The 60° inverted flare seating ensures bubble-tight connections in high-vibration environments. Nickel-plated construction resists hydraulic oil degradation and particulate buildup.
Industrial Applications:
- Pneumatic manifold blocks in packaging machinery
- Coolant line distribution in CNC machining centers
- Vacuum system junctions for semiconductor handling
- Hydraulic test bench instrumentation clusters
- Compressed air branching in automotive assembly robots
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (avoiding first thread).
Torque to 25-30 N·m using crowfoot wrench. Post-installation pressure
test required at 1.25× system pressure for 15 minutes.
Compatibility note:
Not suitable for oxygen systems or acetylene gas. Maximum
angular misalignment tolerance: ±3° between connected ports.
| Property | Property Value |
|---|---|
| sku | X-APD6M16 |
