Airtac X-APD Connector - T-Type Threaded Tee X-APD6M20
AirTAC X-APD6M20 T-Port Tee Fitting Technical Details
- Model: X-APD6M20
- Type: T-shaped metric threaded tee (triple connection)
- Thread standard: ISO 228 (G-series parallel threads)
- Nominal diameter: M20×1.5 (equivalent to G3/4)
- Material: Lead-free brass (CuZn39Pb3) with nickel plating / Optional 303 stainless steel
- Pressure rating: 0.3-1.6 MPa (43.5-232 psi)
- Burst pressure: ≥6.3 MPa (914 psi)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Seal type: Metal-to-metal contact with optional PTFE tape
- Surface roughness: Ra ≤3.2μm
- Weight: 85g (brass) / 120g (stainless steel)
- Dimensions: 60mm(L) × 30mm(W) × 30mm(H)
- Port configuration: 3×G3/4 male threads (BSPP)
- Torque specification: 35-45 N·m (brass) / 50-60 N·m (stainless)
- Fluid compatibility: Air, inert gases, non-flammable hydraulic oils
Heavy-duty pneumatic distribution fitting featuring a forged construction with triple pressure sealing surfaces. The tapered thread design (ISO 228-1) ensures leak-free connections in high-vibration environments. Nickel-plated version includes corrosion-resistant coating exceeding 500hrs salt spray test.
- Pneumatic manifold blocks in automotive assembly robots
- Compressed air distribution in packaging machinery
- Hydraulic test bench plumbing systems
- Semiconductor fab equipment gas lines
- Food processing plant air tool networks
Installation protocol:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Use counter-holding wrench on hex flats (19mm) during tightening.
Max 10° angular misalignment allowed between connected components.
Avoid using with:- Chlorinated lubricants (risk of stress corrosion)
- Ethylene glycol mixtures (accelerates dezincification)
- Pulsating pressures above 25Hz (fatigue risk)
| Property | Property Value |
|---|---|
| sku | X-APD6M20 |
