Airtac X-APD Connector - T-Type Threaded Tee X-APD6M5
AirTAC X-APD T-Type Threaded Tee Connector X-APD6M5 Technical Details
- Model: X-APD6M5
- Type: T-shaped pneumatic tee connector
- Thread standard: Metric fine thread (M5×0.8)
- Material: Brass with nickel plating (body), NBR seals
- Pressure range: 0.1-1.0 MPa
- Temperature range: -5℃ to 80℃
- Proof pressure: 1.5 MPa
- Flow coefficient (Cv): 0.06
- Weight: 14.8±0.5g
- Dimensions: 20mm (L) × 18mm (W) × 16.5mm (H)
- Port configuration: 1 input, 2 output (equal flow division)
- Surface treatment: Electroless nickel plating (8-12μm)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-machined tee connector designed for compact pneumatic systems requiring reliable flow distribution. Features corrosion-resistant nickel plating and anti-vibration thread design, with integrated O-ring groove for leak-free connections. Compatible with ISO 15407-1 standard fittings.
- Branching air supply lines in robotic end effectors
- Modular pneumatic circuit prototyping
- Sensor array air signal distribution
- Medical device pneumatic control systems
- Packaging machine actuator networks
Mounting guidance:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 0.7-1.2 N·m torque using 8mm wrench flat surfaces.
Avoid thread sealants containing silicone.
| Property | Property Value |
|---|---|
| sku | X-APD6M5 |
