Airtac X-APD Connector - T-Type Threaded Tee X-APD6M6
AirTAC X-APD6M6 T-Port Tee Fitting Technical Details
- Model: X-APD6M6
- Type: T-shaped pneumatic tee connector (equal distribution)
- Thread standard: ISO 228 (G-thread) / DIN 3852
- Thread size: M6×1.0 (all three ports)
- Material: Nickel-plated brass (C3771)
- Surface treatment: Electroless nickel plating (5-8μm)
- Pressure range: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Seal type: Integral O-ring (NBR 70±5 Shore A)
- Torque resistance: ≤25 N·m tightening torque
- Flow rate: 250 NL/min @ 0.5 MPa
- Weight: 18.5±0.3g
- Dimensions: 19.8mm (L) × 12.4mm (W) × 12.4mm (H)
- Hex size: 12mm wrench flat
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, REACH SVHC-free
Precision-machined tee connector with triple M6 ports arranged in compact T-configuration, featuring corrosion-resistant nickel plating and self-sealing NBR gasket. The 60° tapered thread design ensures leak-free connections without thread sealant. Internal flow channels are polished to Ra0.8μm for minimal pressure drop.
- Pneumatic circuit branching in tight spaces (robotic arms, CNC tool changers)
- Vacuum system distribution nodes
- Medical device gas line manifolds
- Modular pneumatic test benches
- Food-grade air line systems (when paired with FDA-compliant seals)
Mounting guidance:
Hand-tighten plus 1/4 turn with torque wrench. Use backup wrench on hex flats during assembly.
Avoid overtightening - maximum 3 full rotations after seal contact. Compatible with PTFE tape
(1.5 wraps max) for high-vibration environments.
Not recommended for:
Hydraulic fluids, aggressive chemicals, or temperatures exceeding 120℃.
Replace O-ring (P/N: X-OR6-NBR) every 5 years or 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | X-APD6M6 |
