Airtac X-APD Connector - T-Type Threaded Tee X-APD801
AirTAC X-APD801 T-Port Threaded Tee Fitting Specifications
- Model: X-APD801
- Type: Brass T-shaped pneumatic tee connector
- Thread standard: Metric T-type (Taper thread)
- Port configuration: 3-way equal diameter
- Thread size: M5×0.8 (all ports)
- Material: Lead-free brass (CW617N)
- Surface treatment: Electroless nickel plating (5-8μm)
- Pressure rating: 0.05-1.5 MPa
- Temperature range: -20℃ to 120℃
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Weight: 12.5±0.3g
- Dimensions: 20mm(L) × 15mm(W) × 15mm(H)
- Seal compatibility: Compatible with NBR, PU, and FKM seals
- Vibration resistance: 10-2000Hz, 20G acceleration
- Corrosion resistance: 96hrs salt spray test (NSS)
Precision-machined brass tee connector featuring triple sealing surfaces with 360° leak-proof design. The T-type metric thread ensures secure connections in compact pneumatic systems, while the electroless nickel coating provides enhanced corrosion resistance. Includes integrated O-ring grooves for positive sealing with standard 2mm cross-section rings.
- Branch line connections in SMC-type pneumatic circuits
- Modular pneumatic component assemblies
- Miniature air compressor distribution systems
- Robotic end-effector pneumatic networks
- Medical gas equipment manifolds
- Semiconductor manufacturing tools
Installation guidelines:
Apply 0.3-0.5Nm torque during assembly. Use thread sealant only on male threads,
avoiding contamination of sealing surfaces. For stacked configurations,
maintain minimum 6mm clearance between adjacent fittings.
| Property | Property Value |
|---|---|
| sku | X-APD801 |
