Airtac X-APD Connector - T-Type Threaded Tee X-APD804
AirTAC X-APD804 T-Port Threaded Tee Fitting Specifications
- Model: X-APD804
- Type: T-shaped 3-way brass pneumatic connector
- Material: Nickel-plated brass (CuZn39Pb3)
- Thread standard: BSPP (G-thread)
- Port configuration: 1/4" female threads (all three ports)
- Max working pressure: 1.0 MPa (145 psi)
- Pressure range: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile rubber)
- Surface treatment: Electroless nickel plating (5-8μm)
- Installation torque: 25-30 Nm (18.4-22.1 lbf·ft)
- Weight: 120g ±3g
- Dimensions: 35mm(L) × 35mm(W) × 35mm(H)
- Flow coefficient (Cv): 0.65
- Certification: RoHS compliant
Heavy-duty T-port fitting designed for branching pneumatic circuits in confined spaces. Features triple-sealed threads with integrated O-ring grooves for leak-proof connections. The hexagonal base allows wrench tightening while maintaining precise angular alignment. Compatible with ISO 1179-2 standards.
- Pneumatic tool air distribution systems
- Assembly line automation equipment
- CNC machine auxiliary air circuits
- Packaging machine air manifold splits
- Robotic actuator supply line branching
Installation note:
Apply thread sealant (LOCTITE 577 recommended) to male threads before assembly.
Avoid overtightening - torque wrench required for consistent seal compression.
Maximum angular deviation: ±3° from T-axis alignment.
| Property | Property Value |
|---|---|
| sku | X-APD804 |
