Airtac X-APD Connector - T-Type Threaded Tee X-APD8M10
AirTAC X-APD8M10 T-Port Threaded Tee Fitting Specifications
- Model: X-APD8M10
- Type: T-shaped pneumatic connector with metric threads
- Thread standard: ISO 228 (G-series compatible)
- Port configuration: 3-way (1 inlet / 2 outlets)
- Thread size: M10×1.0 (male threads on all ports)
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Surface treatment: Electroless nickel plating ≥12μm
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 120℃ (with NBR seals)
- Installation torque: 10-15 Nm (recommended with thread sealant)
- Seal type: Embedded O-ring (NBR standard, optional FKM)
- Weight: 32.5±1g
- Dimensions: 30mm (L) × 20mm (W) × 20mm (H)
- Flow coefficient: Cv=0.15
- Pressure drop: ≤0.02 MPa at 500 NL/min
Precision-engineered brass tee connector featuring triple M10 male ports arranged in T-configuration. The nickel-plated body provides corrosion resistance in humid environments, while the pre-installed NBR O-rings ensure leak-free connections. Designed for 5,000+ mating cycles with maintained sealing performance. Compatible with ISO 1179-2 adapters.
- Branching pneumatic lines in compact automation cells
- Modular pneumatic system prototyping
- Compressed air distribution in CNC machine tools
- Vacuum system manifold connections
- Instrumentation air supply splitting
Installation guidelines:
Apply thread sealant only on male threads (not on first two full threads).
Use backup wrench on hex flats during assembly to prevent torsion damage.
Maximum angular misalignment tolerance: ±3° between connected ports.
| Property | Property Value |
|---|---|
| sku | X-APD8M10 |
