Airtac X-APD Connector - T-Type Threaded Tee X-APD8M16
AirTAC X-APD8M16 T-Port Tee Fitting Specifications
- Model: X-APD8M16
- Type: T-shaped metric thread tee connector
- Thread standard: Metric (T-port configuration)
- Thread size: M16×1.5 (all ports)
- Material: Nickel-plated brass (body), NBR seals
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa (653 psi)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Weight: 128g ±2g
- Dimensions: 48mm(L) × 48mm(W) × 32mm(H)
- Surface roughness: Ra ≤3.2μm
- Flow coefficient (Cv): 0.65
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined tee connector with triple M16 ports arranged in T-configuration, featuring corrosion-resistant nickel plating and anti-vibration thread design. The internal flow path is optimized for minimal pressure drop (ΔP ≤0.02MPa @ 1MPa). Compatible with ISO 15407-1 standard pneumatic systems.
- Branch line distribution in robotic arm pneumatic circuits
- Compressed air manifold systems for packaging machinery
- Modular pneumatic test benches
- CNC machine tool air supply networks
- Food processing equipment (FDA-compliant seal version available)
Installation guidance:
Apply 3-4Nm torque during assembly using parallel jaw wrench.
For gas applications, use thread sealant compatible with brass (PTFE tape not recommended).
Maximum angular misalignment tolerance: ±1.5°.
| Property | Property Value |
|---|---|
| sku | X-APD8M16 |
