Airtac X-APD Connector - T-Type Threaded Tee X-APD8M20
AirTAC X-APD8M20 T-Port Threaded Tee Fitting Specifications
- Model: X-APD8M20
- Type: T-shaped pneumatic tee connector
- Thread standard: Metric T-type (triangular thread)
- Port configuration: 3-way (1 inlet, 2 outlets)
- Thread size: M20×1.5 (all ports)
- Material: Nickel-plated brass (CuZn39Pb3)
- Surface treatment: Electroless nickel plating (5-8μm)
- Pressure range: 0.5-1.5 MPa
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Flow coefficient (Cv): 2.4
- Burst pressure: ≥6 MPa
- Weight: 75g ±3g
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H)
- Torque specification: 35-40 N·m
- Vibration resistance: 10-2000Hz, 15G acceleration
Precision-machined T-connector featuring corrosion-resistant construction and enhanced flow dynamics. The asymmetrical internal channels minimize pressure drop (ΔP ≤0.02MPa @1MPa) while maintaining compact dimensions. Sealing grooves are CNC-machined to ±0.01mm tolerance for leak-free operation.
- Branch line distribution in pneumatic automation systems
- Modular pneumatic circuit assembly
- Air preparation unit plumbing
- Robotic end-effector air supply splitting
- Compressed air monitoring systems
- Pneumatic tool manifold connections
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (do not over-tighten).
Use counter-rotation technique during final tightening to align ports.
Maximum angular misalignment tolerance: ±3°.
Pressure test recommended after installation.
| Property | Property Value |
|---|---|
| sku | X-APD8M20 |
