Airtac X-APEG Adapter - T-Type Reducing Tee X-APEG108
AirTAC X-APEG108 T-Type Reducing Tee Fitting Specifications
- Model: X-APEG108
- Type: T-shaped reducing tee with metric threads
- Port configuration: Equal tee with size reduction
- Main port size: PT1/2 (G1/2)
- Branch port size: PT3/8 (G3/8)
- Material: Brass with nickel-plated finish
- Pressure rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Flow coefficient (Cv): 2.1
- Weight: 215g ±5g
- Dimensions: 60mm(L) × 32mm(W) × 32mm(H)
- Thread standard: ISO 228 (G-series parallel threads)
- Seal compatibility: Compatible with air, water, and non-corrosive gases
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: ≤10Hz @ 2mm amplitude
Precision-engineered reducing tee for pneumatic systems requiring flow division with diameter transition. Features corrosion-resistant nickel plating and precision-machined threads for leak-free connections. The T-shape design allows compact installation in confined spaces while maintaining optimal flow characteristics.
- Branch line creation in automated assembly line manifolds
- Tool changer pneumatic circuits in CNC machinery
- Pressure gauge mounting configurations
- Dual-actuator control systems with different flow requirements
- Compressed air distribution in packaging equipment
Installation guidelines:
Use thread sealant tape (PTFE) or liquid sealant on male threads only.
Avoid overtightening (max torque 25N·m). Align flow arrows with main
direction of media flow. Pressure test at 1.5x operating pressure
after installation.
- Pressure drop: ≤0.02MPa @ 0.5MPa inlet pressure
- Max flow velocity: 30 m/s (air), 3 m/s (water)
- Burst pressure: ≥4.0 MPa
| Property | Property Value |
|---|---|
| sku | X-APEG108 |
