Airtac X-APEG Adapter - T-Type Reducing Tee X-APEG86
AirTAC X-APEG T-Type Reducing Tee Connector X-APEG86 Technical Details
- Model: X-APEG86
- Type: T-shaped reducing tee with metric threads
- Primary material: Anodized aluminum alloy (AL6061-T6)
- Port configuration: 1/2" (G1/2) main line → 3/8" (G3/8) branch
- Thread standards: ISO 228 (BSPP) compatible, NPT optional
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 150℃ (-4°F to 302°F)
- Surface hardness: HV 120-140
- Weight: 85g ±2g
- Dimensions: 72mm(L) × 48mm(W) × 34mm(H)
- Seal compatibility: Works with NBR, FKM, or EPDM O-rings
- Flow coefficient (Cv): 2.8
- Certifications: RoHS compliant, ISO 9001 manufactured
Precision-engineered reducing tee for compressed air systems requiring branch line downsizing. Features triple-helix thread reinforcement and oxidation-resistant coating. Includes integrated flow guide vanes to minimize turbulence at the junction. Compatible with all standard pneumatic tubing materials including PU, NY, and PE.
- Multi-zone pressure regulation in CNC machine tool manifolds
- Air supply distribution for automated assembly line actuators
- Vacuum system plumbing in packaging machinery
- Compressed air networks requiring staged pressure reduction
- Mobile equipment pneumatic circuits with space constraints
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads. Tighten with 12-15 N·m torque using a crowfoot wrench.
Avoid overtightening - maximum angular rotation after hand-tight is 1.5 turns. Position branch port
vertically upward to prevent condensate accumulation.
Not recommended for:
Hydraulic fluids above ISO VG 32, pulsating pressures exceeding 5 Hz frequency,
or systems using phosphate ester-based lubricants.
| Property | Property Value |
|---|---|
| sku | X-APEG86 |
