Airtac X-APHF Connector - Series Swivel Joint X-APHF1004
AirTAC X-APHF Series Tandem Toggle Joint - X-APHF1004 Technical Details
- Model: X-APHF1004
- Type: Tandem toggle joint with male-male thread
- Material: Reinforced POM (Polyoxymethylene) body with brass insert
- Thread specification: M10x1.25 (ISO 261 metric fine thread)
- Max torque resistance: 5.8 N·m (repetitive operation)
- Pressure rating: 0.05–0.7 MPa (7–100 PSI)
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Swivel angle: ±25° axial rotation capability
- Weight: 78g ±2g (including packing washers)
- Dimensions: 48mm(L) × 32mm(W) × 24mm(H)
- Surface finish: Ra 3.2μm on mating surfaces
- Vibration resistance: 10–2000Hz @ 15g acceleration
- Cycle life: 500,000+ cycles @ 0.5 MPa
Dual-axis pivot joint featuring precision-machined internal ball bearings for multi-directional force transmission in confined spaces. The chromium-plated steel pivot pin with PTFE coating ensures smooth rotation and corrosion resistance. Designed for applications requiring angular compensation in both horizontal and vertical planes.
- Robotic arm wrist joint articulation
- Conveyor system redirection mechanisms
- Packaging machine clamp positioning
- Automated assembly line tool changers
- Semiconductor handling equipment
Installation protocol:
Apply 242 Loctite® on male threads during assembly. Torque to 3.2–3.8 N·m
using calibrated wrench. Lubricate pivot point monthly with MIL-PRF-32033 grease.
- Use with AirTAC PU-06 polyurethane tubing (ID4mm)
- Combine with X-SV10M speed controller for motion damping
- Match with X-QS4 quick-connect couplers for modular systems
| Property | Property Value |
|---|---|
| sku | X-APHF1004 |
