Airtac X-APHF Connector - Series Swivel Joint X-APHF10M10
AirTAC X-APHF10M10 Series Tandem Swivel Joint Specifications
- Model: X-APHF10M10
- Type: 45° adjustable tandem swivel with M10 thread
- Thread specification: M10×1.0 male thread (ISO 228 G1/8 equivalent)
- Material: Nickel-plated brass body with PPS composite lever
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max flow rate: 350 NL/min (at 0.5 MPa)
- Temperature range: -20℃ to 80℃ (non-condensing)
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Rotation angle: ±5° axial misalignment compensation
- Tightening torque: 2.5–3.0 N·m (22–26.5 lb-in)
- Weight: 48g ±2g
- Dimensions: 32mm(Ø) × 28mm(H) body / 55mm(L) including lever
- Surface hardness: HV300 (lever component)
- Vibration resistance: 10–2000Hz, 15G acceleration
Precision-engineered swivel joint featuring dual-axis compensation for pneumatic line stress reduction. The chrome-plated brass construction provides corrosion resistance in humid environments, while the ergonomic lever enables single-hand operation with 180° rotation lock mechanism. Compatible with ISO 8434-1/DIN 2353 fittings.
- Robotic end-effector tool changers requiring flexible air supply
- CNC machine coolant line quick disconnects
- Semiconductor wafer handling vacuum systems
- Packaging line rotary union replacements
- Medical device pneumatic assembly stations
Installation protocol:
Apply 3 drops of PTFE-based lubricant (AIRMATE AL-300 recommended)
on threads before installation. Perform torque verification every
2,000 operating cycles using 1/4" drive torque wrench.
Max allowable radial load: 15N.
| Property | Property Value |
|---|---|
| sku | X-APHF10M10 |
