Airtac X-APHF Connector - Series Swivel Joint X-APHF10M12
AirTAC X-APHF Series Tandem Elbow Joint X-APHF10M12 Technical Details
- Full model designation: X-APHF10M12
- Series: High-flow compact tandem elbow
- Body material: Nickel-plated brass (CuZn39Pb3)
- Seal material: HNBR rubber (temperature-enhanced variant)
- Thread specification: M12×1.0 male thread (ISO 1179-2 compliant)
- Max working pressure: 1.5 MPa (217 psi)
- Pressure test: 2.25 MPa hydraulic burst-proof
- Operating temperature: -20℃ to 80℃ (continuous use)
- Peak temperature resistance: 120℃ (intermittent)
- Flow coefficient (Cv): 0.45
- Swivel range: 340° continuous rotation
- Leakage rate: <5×10⁻⁸ Pa·m³/s (helium tested)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 32.5g ±0.8g
- Dimensions: 40mm(L) × 22mm(W) × 18.5mm(H)
- Vibration resistance: 10-2000Hz, 20G acceleration
Precision-engineered tandem elbow connector featuring dual O-ring seals and anti-vibration thread locking. The chamfered port design minimizes pressure drop (ΔP <0.02MPa @1MPa) while maintaining 5μm filtration compatibility. Gold-anodized adjustment nuts provide wear-resistant torque control (1.2-1.8N·m recommended).
- Robotic welding arm pneumatic circuits (6-axis articulation points)
- CNC machine tool coolant line quick-connect systems
- Pharmaceutical filling machine sterile air networks
- Lithium battery assembly vacuum chuck manifolds
- Semiconductor wafer handling EFEM pneumatic systems
Installation protocol:
Apply 25-30 in-lb torque using flank-contact wrench. Perform 5 full rotation
cycles post-installation to seat seals. Avoid PTFE tape - use LOCTITE 577
instead for high-vibration environments.
| Property | Property Value |
|---|---|
| sku | X-APHF10M12 |
