Airtac X-APHF Connector - Series Swivel Joint X-APHF10M20
AirTAC X-APHF10M20 Series Elbow Tandem Joint Specifications
- Model: X-APHF10M20
- Type: 90° Tandem Swivel Joint with Male Threads
- Thread Specification: M10×1.25 (Male) × M20×1.5 (Male)
- Material: Anodized Aluminum Allody (Body), Stainless Steel Pivot
- Max Torque Resistance: 18 N·m
- Rotation Angle: ±5° Axial Adjustment Range
- Pressure Rating: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃ (Dry Air)
- Weight: 168g ±2g
- Dimensions: 52mm(Length) × 34mm(Width) × 48mm(Height)
- Surface Hardness: HV400±20 (Pivot Area)
- Leakage Rate: <0.1 NL/min @ 0.5 MPa
- Vibration Resistance: 10-2000Hz, 15m/s²
Precision tandem elbow joint featuring dual-stage sealing (X-ring + PTFE backup) for leak-free performance in dynamic pneumatic systems. The hardened pivot mechanism enables 25,000+ rotation cycles at rated load. Compatible with ISO 16030 standard ports, with anti-vibration grooves for tube retention.
- Multi-axis robotic end effectors requiring compact flow routing
- CNC machine tool coolant line connections
- Packaging machinery with oscillating actuator assemblies
- Semiconductor wafer handling vacuum/pneumatic hybrids
- Medical device pneumatic control manifolds
Installation Protocol:
Apply 2-3Nm preload torque during assembly. Use Loctite 243 on male threads.
For vertical mounting orientations, install dust sleeve (AS-10 accessory recommended).
Maximum 15° lateral bending moment applied.
| Property | Property Value |
|---|---|
| sku | X-APHF10M20 |
