Airtac X-APHF Connector - Series Swivel Joint X-APHF1201
AirTAC X-APHF Series Tandem Swivel Joint - X-APHF1201 Technical Details
- Model: X-APHF1201
- Type: Tandem swivel joint with dual-axis rotation
- Port size: 1/8" NPT (BSPP optional)
- Max working pressure: 0.1-0.8 MPa
- Leakage rate: ≤0.3 NL/min @ 0.6 MPa
- Body material: Anodized aluminum alloy (A6063-T5)
- Seal material: HNBR rubber (-20℃ to 120℃ compatible)
- Rotation angle: ±25° axial tilt, 360° continuous rotation
- Surface treatment: Chromate conversion coating
- Weight: 52g ±2g
- Dimensions: 40mm (L) × 25mm (W) × 30mm (H)
- Thread engagement depth: 8mm minimum
- Vibration resistance: 10-2000Hz, 15G acceleration
Precision-engineered tandem swivel joint featuring low-torque rotation and anti-vibration locking nuts. The dual O-ring design prevents air leakage during dynamic motion cycles. Nickel-plated brass internals ensure corrosion resistance in humid environments. Compatible with ISO 8573-1:2010 Class 3 compressed air.
- Robotic arm end-effector tooling with multi-axis movement
- Rotary index table pneumatic connections
- PCB handling equipment requiring twist-free hose routing
- Food processing machinery (FDA-compliant grease option available)
- Semiconductor wafer transfer systems
Installation protocol:
Apply 2-3Nm torque during assembly. Use thread sealant only on male ports.
For pulsation environments, install 100mm downstream from valve.
Maximum angular misalignment tolerance: 1.5° per joint.
| Property | Property Value |
|---|---|
| sku | X-APHF1201 |
