Description
AirTAC X-APHF Series Tandem Swivel Joint - X-APHF1202 Technical Details
- Model: X-APHF1202
- Thread specification: 1/8" BSPP (G1/8)
- Material: Nickel-plated brass body + PPS resin lever
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -5℃ to 80℃ (no ice formation)
- Rotation angle: ±15° axial rotation capability
- Flow coefficient (Cv): 0.08
- Leakage rate: ≤0.1 NL/min at 0.5 MPa
- Weight: 28.5g ±1g
- Dimensions: 42mm(Length) × 22mm(Width) × 38mm(Height)
- Surface hardness: HV400-450 (nickel plating)
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
- Durability cycles: 500,000 rotations (load ≤0.3MPa)
High-precision tandem swivel joint featuring dual-axis rotation compensation with low torque operation. The optimized flow path design reduces pressure drop by 15% compared to standard models. Sealed with HNBR O-rings for chemical resistance against lubrication oils and mild acids.
Industrial Applications:
- Multi-axis robotic end effectors requiring flexible tubing
- Semiconductor wafer handling equipment
- Rotary index table pneumatic connections
- Plastic injection molding machine ejector systems
- Pharmaceutical filling machine tooling heads
Installation protocol:
Apply 2-3 drops of ISO VG32 turbine oil on swivel surfaces before initial operation.
Avoid overtightening - recommended torque 1.2-1.5N·m. For vertical installations,
use support bracket AP-MB03 (sold separately).
| Property | Property Value |
|---|---|
| sku | X-APHF1202 |
