Airtac X-APHF Connector - Series Swivel Joint X-APHF1203
$5.49
Regular price
$12.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APHF1203
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APHF1203 Series Tandem Elbow Joint Technical Details
- Model: X-APHF1203
- Type: Tandem elbow joint with swivel mechanism
- Body material: Anodized aluminum alloy (AL6061-T6)
- Thread specification: M5×0.8 female threads (dual ports)
- Swivel range: 360° continuous rotation + ±15° axial tilt
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Mounting torque: 1.2-1.5 N·m recommended
- Flow coefficient (Cv): 0.45
- Protection rating: IP40 (dust protected)
- Weight: 95g ±2g
- Dimensions: 60mm(L) × 30mm(W) × 30mm(H)
Dual-axis adjustable pneumatic connector featuring anti-vibration lock nuts and self-aligning ball bearings. The staggered port design enables compact plumbing in multi-cylinder configurations. Chrome-plated brass internal sleeves prevent thread galling during repeated adjustments.
Industrial Applications:
- Multi-axis robotic arm pneumatic routing
- CNC machine tool clamp manifolds
- Automated packaging line air distribution
- Semiconductor wafer handling equipment
- Cleanroom-compatible production systems
Installation guidance:
Apply 2-3 drops of pneumatic-grade lubricant (ISO VG32) on swivel joints before assembly.
Avoid overtightening - use torque wrench for precise installation.
Maximum misalignment tolerance: 0.5mm between connected components.
| Property | Property Value |
|---|---|
| sku | X-APHF1203 |
