Airtac X-APHF Connector - Series Swivel Joint X-APHF1204
AirTAC X-APHF Series Tandem Toggle Joint Specifications: X-APHF1204
- Model: X-APHF1204
- Type: Tandem toggle joint with swivel mechanism
- Thread specification: 1/4" BSPP (G1/4)
- Material: Anodized aluminum alloy body + POM (polyoxymethylene) rotating parts
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 80℃
- Rotation angle: ±5° axial compensation + 360° continuous rotation
- Torque resistance: ≤2.5 N·m (sealed state)
- Surface hardness: HV400 (aluminum components)
- Leakage rate: <5×10⁻⁴ Pa·m³/s (at 0.5 MPa)
- Weight: 0.25 kg ±5%
- Dimensions: 40mm (L) × 30mm (W) × 20mm (H) per joint segment
- Connection spacing: 12mm between ports (center-to-center)
- Vibration resistance: 10-2000 Hz, 15G acceleration
High-precision tandem toggle joint featuring dual-axis compensation for complex piping alignment. The diamond-textured grip surface enhances anti-slip performance during manual adjustments. Integrated with wear-resistant bushings that withstand >500,000 rotation cycles under rated load.
- Multi-axis robotic arm pneumatic circuits
- CNC machine tool coolant line connections
- Semiconductor wafer handling equipment
- High-vibration environments like injection molding machines
- Modular pneumatic systems requiring quick reconfiguration
Installation protocol:
Apply 2-3 drops of ISO VG32 hydraulic oil on rotating surfaces before initial use.
Maximum recommended tightening torque: 14 N·m. Use backup wrench within 15mm of
joint body during assembly to prevent torsion stress.
| Property | Property Value |
|---|---|
| sku | X-APHF1204 |
