Airtac X-APHF Connector - Series Swivel Joint X-APHF12M12
AirTAC X-APHF12M12 Series Tandem Elbow Joint Specifications
- Model: X-APHF12M12
- Type: Tandem swivel elbow joint (male-threaded)
- Thread specification: M12×1.25 (ISO 1179-2 standard)
- Material: Nickel-plated brass body with CRCA steel clamp
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Flow rate capacity: 500 NL/min (at 0.5 MPa)
- Torque resistance: ≤3 N·m tightening torque
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 48g ±2g
- Dimensions: 32mm (L) × 24mm (W) × 18mm (H)
- Rotation angle: 360° continuous rotation capability
- Vibration resistance: 10-2000Hz, 5G acceleration
High-density tandem elbow joint featuring a double-ball-bearing swivel mechanism for leak-free performance under dynamic motion. The chrome-plated steel clamp provides 25% higher grip force compared to standard models. Precision-machined threads include anti-vibration notches to prevent loosening in high-cycle applications.
- Multi-axis robotic arm pneumatic tool changers
- CNC machine tool coolant line connections
- High-frequency packaging machine actuator systems
- Automotive assembly line leak testing equipment
- Semiconductor wafer handling vacuum/pneumatic hybrids
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads. Use torque wrench for final tightening (2.5-3 N·m).
Perform pressure test at 1.8 MPa (260 psi) for 10 minutes during initial commissioning.
| Property | Property Value |
|---|---|
| sku | X-APHF12M12 |
