Airtac X-APHF Connector - Series Swivel Joint X-APHF12M16
AirTAC X-APHF12M16 Series Swivel Joint Specifications
- Model: X-APHF12M16
- Type: 360° Rotating Tandem Elbow Fitting
- Thread Specification: M16×1.5 (Male Thread Both Ends)
- Tube OD Compatibility: 12mm (9/16") Pneumatic Tubing
- Material: Brass with Nickel Plating (Stainless Steel Optional)
- Max Working Pressure: 1.5 MPa (217 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: HNBR (Hydrogenated Nitrile) O-Rings
- Torque Resistance: ≤3 N·m (Anti-Loosening Design)
- Weight: 82g ±2g
- Dimensions: 56mm(L) × 32mm(W) × 32mm(H)
- Rotational Friction: <0.3 N·m at 0.5 MPa
- IP Rating: IP54 (Dust Protected, Splash Resistant)
Dual-axis rotary joint featuring 360° continuous rotation with zero leakage design. Precision-machined with dual ball-bearing structure for smooth torque transmission. Compatible with ISO 8434-1/DIN 2353 metric tube standards. Includes anti-vibration washers for high-cycle applications.
- Robotic welding arm pneumatic line connections
- Rotary indexing table air supply systems
- CNC machine tool coolant line swivel points
- Automated packaging line gripper actuators
- Semiconductor wafer handling equipment
Installation Protocol:
Apply 2-3 drops of PTFE-based lubricant on threads before assembly.
Tighten with 18-22 N·m torque using crowfoot wrench.
Avoid axial misalignment exceeding 3° during piping layout.
| Property | Property Value |
|---|---|
| sku | X-APHF12M16 |
