Airtac X-APHF Connector - Series Swivel Joint X-APHF12M20
AirTAC X-APHF12M20 Series Tandem Swivel Joint Specifications
- Model: X-APHF12M20
- Type: Tandem swivel elbow joint (male-threaded)
- Body material: Nickel-plated brass (stainless steel optional)
- Thread specification: M20×1.5 (external thread both ends)
- Max working pressure: 1.5 MPa
- Operating temperature: -20°C to 80°C
- Swivel angle: ±25° axial rotation
- Flow capacity: 900 Nl/min (at 0.7 MPa)
- Weight: 168g ±5g
- Dimensions: 60mm(L) × 30mm(W) × 30mm(H)
- Seal material: HNBR with PTFE coating
- Surface hardness: HV400-450 (nickel plating)
- Vibration resistance: 10-2000 Hz, 15G acceleration
High-torque swivel joint featuring dual-axis articulation for complex pneumatic line routing. Precision-machined with triple-layered sealing (main seal + dust seal + anti-extrusion ring) for leak-free performance in high-vibration environments. The tandem design allows simultaneous multi-directional adjustments without flow restriction.
- Robotic welding arm pneumatic tooling
- CNC machine rotating tool changers
- Automated packaging line rotary unions
- Semiconductor wafer handling robots
- Hydraulic hybrid vehicle test benches
Installation protocol:
Apply 2-3 drops of ISO VG32 hydraulic oil on threads before assembly.
Tighten with 25-30 N·m torque using flank-contact wrench.
Avoid overtightening beyond 35° rotation after seal contact.
| Property | Property Value |
|---|---|
| sku | X-APHF12M20 |
