Airtac X-APHF Connector - Series Swivel Joint X-APHF4M10
AirTAC X-APHF Series Tandem Elbow Fitting X-APHF4M10 Technical Details
- Model Code: X-APHF4M10
- Type: Multi-axis adjustable tandem elbow joint
- Thread Specification: M10×1.0 male thread (ISO metric standard)
- Material: Nickel-plated brass body + POM (polyoxymethylene) rotating components
- Max Operating Pressure: 1.0 MPa (10 bar)
- Temperature Range: -20℃ to 80℃ (continuous use)
- Swivel Angle: ±15° axial rotation with 360° continuous lateral rotation
- Tube Compatibility: 4mm OD polyurethane/nylon tubing (tightening range 3.5-4.5mm)
- Seal Type: Integrated NBR O-ring with anti-vibration lock
- Weight: 28g ±2g (without tubing)
- Dimensions: 34mm(L) × 22mm(W) × 18mm(H) (body only)
- Torque Resistance: 0.8 N·m max at full extension
- Vibration Resistance: 10-55Hz @ 1.5mm amplitude
Precision-machined flow-optimized fitting featuring dual-axis articulation for complex pneumatic routing. The chrome-plated brass construction ensures corrosion resistance in humid environments, while the POM rotating collar provides smooth torque-free adjustment. Includes integrated dust shield for particulate protection.
- Robotic end-effector tool changers requiring multi-directional air supply
- CNC machine tool cooling line connections with space constraints
- Packaging machinery with vibrating components needing secure leak-proof joints
- Laboratory automation systems requiring frequent hose reconfiguration
- Semiconductor handling equipment demanding particulate-free airflow
Installation protocol:
Apply 2-3 drops of pneumatic sealant (P80 grade or equivalent) on threads before assembly.
Tighten to 1.2-1.5 N·m using crowfoot wrench - over-tightening may compromise swivel function.
Perform 5 full rotation cycles post-installation to seat seals properly.
| Property | Property Value |
|---|---|
| sku | X-APHF4M10 |
