Airtac X-APHF Connector - Series Swivel Joint X-APHF4M12
AirTAC X-APHF Series Tandem Elbow Joint X-APHF4M12 Technical Details
- Model: X-APHF4M12
- Type: Tandem elbow joint with swivel mechanism
- Thread specification: M12×1.5 (male thread both ends)
- Material: Nickel-plated brass body, NBR seals
- Operating pressure: 0.05–0.8 MPa
- Temperature range: -5℃ to 60℃
- Rotation angle: ±30° adjustable
- Torque resistance: 5 N·m max (rotational)
- Installation torque: 2.5–3.5 N·m recommended
- Weight: 58±2g
- Dimensions: 60mm(L) × 32mm(W) × 32mm(H)
- Surface treatment: Electroless nickel plating (8-12μm)
- Thread engagement length: 15mm
- Pressure drop: ≤0.02 MPa @ 0.5 MPa supply
- Vibration resistance: 10–55Hz @ 1.5mm amplitude
- Protection rating: IP40 (dust protected)
High-density brass tandem elbow designed for precision pneumatic circuit routing in confined spaces. Features dual-axis adjustability with precision ground threads for leak-free connections. The 360° swivel design allows flexible tube orientation while maintaining structural rigidity under cyclic loading.
- Robotic arm end effector pneumatic routing
- Multi-axis actuator manifold interconnections
- Packaging machine tooling plate installations
- CNC machine coolant line adapters
- Semiconductor fab equipment gas lines
Installation protocol:
Apply 242 Loctite® on threads and hand-tighten before final torque application.
Avoid side-loading during operation - maximum lateral force 50N.
Perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APHF4M12 |
