Airtac X-APHF Connector - Series Swivel Joint X-APHF4M5
AirTAC X-APHF4M5 Series Tandem Elbow Joint Specifications
- Model: X-APHF4M5
- Type: Tandem elbow joint (swivel type)
- Body material: Nickel-plated brass (C3604)
- Thread specification: M5×0.8 (male thread both ends)
- Tube compatibility: Ø4mm polyurethane/nylon tubing
- Working pressure: 0.1-0.8 MPa
- Temperature range: -5℃ to 80℃
- Rotation angle: 360° continuous rotation (each joint)
- Weight: 15g ±0.5g
- Dimensions: 20mm(L) × 16mm(W) × 12mm(H) per joint unit
- Seal material: NBR (Nitrile) standard / FKM (Viton) optional
- Surface hardness: HV200±20 (nickel plating)
- Torque resistance: ≤0.15N·m at 0.6MPa
Precision tandem elbow joint featuring dual-axis swivel mechanism for complex pneumatic routing. The stacked design allows 720° cumulative rotation (360°×2) with minimal pressure drop. Electroplated finish prevents corrosion in humid environments. Includes self-aligning seals for vibration resistance.
- Multi-axis robotic arm pneumatic connections
- CNC machine tool cooling spray systems
- Semiconductor wafer handling equipment
- Automated test jigs requiring rotational flexibility
- Medical device pneumatic circuit junctions
Installation guidelines:
Apply 2-3 drops of pneumatic oil (ISO VG32) before assembly.
Maximum recommended tightening torque: 0.8N·m.
Avoid simultaneous rotation of both joints beyond 180° during pressure cycles.
| Property | Property Value |
|---|---|
| sku | X-APHF4M5 |
