Airtac X-APHF Connector - Series Swivel Joint X-APHF4M6
AirTAC X-APHF4M6 Series Elbow Joint Specifications
- Model: X-APHF4M6
- Type: Tandem swivel joint (male-threaded)
- Thread specification: M6×1.0 external thread (ISO metric standard)
- Material: Nickel-plated brass body, PPS composite rotating parts
- Max working pressure: 0.05–0.7 MPa (7–100 PSI)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Swivel angle: ±25° free rotation with 360° axial adjustment
- Seal type: Double-layer NBR O-ring (oil-resistant)
- Flow coefficient (Cv): 0.15
- Weight: 19.5g ±0.3g
- Dimensions: 24.5mm(L) × 14.2mm(W) × 14.2mm(H)
- Surface hardness: HV350-400 (plated layer)
- Torque resistance: ≤0.15N·m at 0.5MPa
Multi-axis adjustable pneumatic connector designed for complex piping layouts requiring angular compensation. Features anti-vibration structure with precision-machined ball socket interface, reducing tubing stress during dynamic movements. Rated for 500,000+ swivel cycles with <0.01mm radial play.
- Robotic end-effector tool changers
- CNC machine rotating workholding fixtures
- Semiconductor wafer handling arms
- High-cycle packaging machine diverters
- Medical device pneumatic rotary joints
Installation protocol:
Hand-tighten with 1/2 additional turn using 8mm wrench. Apply Loctite 542
thread sealant for vacuum applications. Avoid side-loading exceeding 15N
during alignment. Perform torque check every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | X-APHF4M6 |
