Airtac X-APHF Connector - Series Swivel Joint X-APHF4M8
AirTAC X-APHF4M8 Series Tandem Swivel Joint Specifications
- Model: X-APHF4M8
- Type: Tandem swivel elbow joint (male thread)
- Thread specification: M8×1.0 (ISO metric)
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) with PU coating
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -5℃ to 80℃ (with intermittent peaks at 100℃)
- Swivel range: 360° continuous rotation
- Tilt angle: ±3° angular compensation
- Flow rate: 250 NL/min (at 0.5 MPa)
- Weight: 18g ±0.5g
- Dimensions: 32mm(L) × 16mm(W) × 16mm(H)
- Surface finish: Ra0.8μm (internal flow path)
- Vibration resistance: 10-2000Hz, 5G acceleration
- Certification: RoHS compliant, REACH SVHC-free
Precision-engineered tandem swivel joint featuring dual O-ring sealing and anti-vibration lock nuts. The 45° elbow design enables compact piping layouts while maintaining full rotational capability. Anodized color bands (blue body with yellow adjustment collar) indicate connection status.
- Multi-axis robotic arm end effectors
- CNC machine tool coolant line connections
- Semiconductor wafer handling vacuum systems
- Automated packaging line pneumatic grippers
- Medical device pneumatic control panels
Installation protocol:
Apply 2-3 drops of pneumatic sealant (PST-3 type) on threads before assembly.
Torque specification: 1.2-1.5 N·m. Perform clockwise rotation check every
500 operating cycles. Not compatible with phosphate ester fluids.
| Property | Property Value |
|---|---|
| sku | X-APHF4M8 |
