Airtac X-APHF Connector - Series Swivel Joint X-APHF604
AirTAC X-APHF604 Series Elbow Fitting - Tandem Swivel Joint Specifications
- Model: X-APHF604
- Type: Tandem swivel elbow (360° rotation)
- Thread specification: 1/8" BSPP (G1/8)
- Material: Brass (Ni-plated surface)
- Seal material: HNBR rubber (high nitrile)
- Operating pressure: 0.5-1.5 MPa
- Temperature range: -20℃ to 80℃
- Swivel angle: ±15° axial adjustment
- Burst pressure: ≥3.0 MPa
- Leakage rate: ≤0.1 mL/min @ 0.5 MPa
- Weight: 82g ±2g
- Dimensions: 35mm(L) × 20mm(W) × 15mm(H)
- Surface roughness: Ra0.8μm (flow path)
- Protection rating: IP40
Precision tandem swivel joint featuring dual-axis adjustability for complex pneumatic routing. The through-hole design minimizes pressure drop (ΔP ≤0.02 MPa @ 1.0 MPa) while maintaining 360° continuous rotation capability. Nickel-plated surface provides corrosion resistance in humid environments (RH ≤95%).
- Multi-axis robotic arm end effectors
- Rotary index table pneumatic connections
- CNC machine tool clamp actuator alignment
- Semiconductor wafer handling systems
- Packaging line rotary joint replacements
Installation protocol:
Apply 2-3 drops of pneumatic sealant (viscosity ≤32 cSt) on threads before assembly.
Tighten to 12-15 N·m torque using crowfoot wrench. Perform 5 full rotation cycles
post-installation to distribute lubricant evenly.
| Property | Property Value |
|---|---|
| sku | X-APHF604 |
