Airtac X-APHF Connector - Series Swivel Joint X-APHF6M12
AirTAC X-APHF6M12 Series Elbow Joint Technical Details
- Full model designation: X-APHF6M12
- Connection type: M12×1.25 male thread (metric fine)
- Body material: Nickel-plated brass (CuZn39Pb3)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Max working pressure: 1.0 MPa (145 psi)
- Temperature tolerance: -20℃ to 80℃ (-4°F to 176°F)
- Rotation angle: 340° free swivel with ±5° axial tilt
- Flow coefficient (Cv): 0.25
- Pressure drop: ≤0.02 MPa @ 0.5 MPa supply
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Weight: 98g ±2g (including packaging)
- Dimensions: 38mm (L) × 24mm (W) × 54mm (H)
- Surface hardness: HV400-450
- Corrosion resistance: 96hrs salt spray test passed
- Certifications: RoHS compliant, REACH SVHC-free
Precision-engineered swivel joint featuring dual O-ring sealing and anti-vibration lock nuts. The diamond-knurled surface ensures secure grip during installation. Designed for high-cycle applications requiring frequent directional adjustments in confined spaces. Compatible with ISO 15407-1 standard fittings.
- Robotic arm end-effector pneumatic circuits
- Multi-axis CNC machine tool coolant line connections
- Semiconductor wafer handling vacuum/pressure systems
- Food-grade compressed air distribution networks
- High-cycle packaging machine actuator linkages
Installation protocol:
Apply 3-5Nm torque using crowfoot wrench. Avoid thread sealant -
use PTFE tape only on male threads. Perform 10 full rotation cycles
post-installation to seat seals properly.
Compatibility note:
Not suitable for ultra-high vacuum (UHV) applications below 10-3 Pa
or hydrocarbon-based media. Requires monthly lubrication with
ISO VG32 pneumatic oil in dusty environments.
| Property | Property Value |
|---|---|
| sku | X-APHF6M12 |
