Airtac X-APHF Connector - Series Swivel Joint X-APHF6M20
AirTAC X-APHF Series Tandem Elbow Joint X-APHF6M20 Technical Details
- Model: X-APHF6M20
- Type: Tandem elbow swivel joint (dual-axis adjustable)
- Thread specification: M20×1.5 (ISO 228 G3/4 optional)
- Material: Nickel-plated brass body with CRMoV alloy pivot
- Operating pressure: 0.05–1.5 MPa (7–217 PSI)
- Max torque resistance: 25 N·m at 0.6 MPa
- Rotation range: ±30° axial rotation / ±15° lateral tilt
- Seal type: Double-lip NBR seals with PTFE backup rings
- Temperature range: -20℃ to 80℃ (dry air)
- Surface treatment: Electroless nickel plating (8–12μm)
- Weight: 184g ±3g
- Dimensions: 68mm(L) × 34mm(W) × 34mm(H)
- Vibration resistance: 5–2000 Hz, 20G acceleration
- Leakage rate: ≤3 bubbles/min under 0.5 MPa (ISO 6952)
High-mobility pneumatic connector engineered for complex piping layouts requiring multi-axis articulation. Features self-aligning ball-and-socket design with hardened pivot pins for reduced wear. The chrome-molybdenum-vanadium alloy core withstands repeated articulation cycles while maintaining airtight integrity. Compatible with ISO 8573-1:2010 Class 3 compressed air.
- Robotic end-effector tool changers with dynamic air supply
- CNC machine tool coolant line articulations
- Automated packaging line rotary unions
- Semiconductor wafer handling vacuum systems
- Food processing equipment with CIP/SIP requirements
Installation protocol:
Apply 360° thread sealant (LOCTITE 577 recommended) and torque to 35–40 N·m.
Perform alignment calibration after installation - maximum allowable
lateral offset is 0.5mm. Lubricate pivot points monthly with MIL-PRF-81322F
grease in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | X-APHF6M20 |
