Airtac X-APHT Adapter - Brass Hex X-APHT401
$6.27
Regular price
$13.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APHT401
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APHT401 Brass External Hexagon Fitting Specifications
- Model: X-APHT401
- Type: External hexagon straight thread connector
- Material: Lead-free brass (CW617N)
- Thread Standard: Metric thread (M5×0.8)
- Hex Size: 8mm across flats
- Max Working Pressure: 1.5 MPa (15 bar)
- Temperature Range: -20℃ to 120℃
- Seal Type: Integrated EPDM O-ring (pre-installed)
- Surface Treatment: Electroplated nickel (3-5μm thickness)
- Weight: 22g ±0.5g
- Dimensions: 40mm(L) × 8mm(W) × 8mm(H)
- Port Size: 4mm pneumatic bore
- Vibration Resistance: ≤10Hz/1.5mm amplitude
- Corrosion Rating: 96hrs neutral salt spray test passed
Precision-machined brass fitting with anti-vibration grooves and corrosion-resistant plating. Features a 360° rotatable collar for tool-free tube adjustment and dual-stage sealing with embedded O-ring. Compatible with PU/Nylon tubing (ID 4mm).
Typical Applications:
- Pneumatic cylinder port connections
- Compressed air distribution manifolds
- Industrial robot end-effector tooling
- CNC machine lubrication lines
- Packaging equipment air circuits
- Medical gas delivery systems (non-oxygen)
Installation protocol:
Use 8mm wrench for tightening (max torque 2.5N·m). Apply thread sealant only on male threads,
avoid contaminating O-ring. Perform pressure test at 1.75MPa after installation.
| Property | Property Value |
|---|---|
| sku | X-APHT401 |
