Airtac X-APHT Adapter - Brass Hex X-APHT402
$6.27
Regular price
$13.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APHT402
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APHT402 Brass Hexagon Fitting Specifications
- Model: X-APHT402
- Type: Full brass hexagon union connector
- Thread standard: Metric (M5×0.8) / Optional NPT/BSPP
- Port size: 1/4" (6.35mm nominal)
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥6.0 MPa
- Temperature range: -20℃ to 120℃
- Seal material: NBR (Nitrile) O-ring
- Surface treatment: Electroplated nickel (3-5μm)
- Torque resistance: 12-15 N·m max
- Weight: 48g ±2g
- Dimensions: 25mm (L) × 16mm (W) × 16mm (H)
- Compliance: RoHS 2.0, REACH SVHC
Precision-machined brass fitting with 6-point wrench flats for secure installation in high-vibration environments. Features dual-sealing structure with embedded O-ring and metal-to-metal contact. Rated for compressed air, inert gases, and water applications.
Recommended Applications:
- Pneumatic cylinder port connections
- Air compressor manifold assemblies
- CNC machine tool coolant lines
- Vacuum system junctions
- Hydraulic test bench fittings
Installation guidance:
Apply 1.5-2 wraps of PTFE tape on male threads (clockwise winding).
Tighten using 12mm wrench - avoid over-torqueing beyond 15N·m to prevent
thread deformation. Perform pressure test at 1.1× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APHT402 |
